Touch Screen Digital Gloss Meter 60 Degree NHG60 1000gu For Car Paint Glossy Test

Touch Screen Digital Gloss Meter 60 Degree NHG60 1000gu For Car Paint Glossy Test

Product Details:

Place of Origin: Shenzhen China
Brand Name: 3nh
Certification: CE, TUV, FCC, RoHs
Model Number: NHG60

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: Please send inquiry
Packaging Details: 30*20*10cm, 1kg, with a carrying bag
Delivery Time: 1-5 Days
Payment Terms: T/T
Supply Ability: 1000 Units per Month
Get Best Price Contact Now

Detail Information

Measuring Angle: 60° Measuring Area(mm): 60°:9x15
Measuring Range(GU): 60°:0~1000 Division Value: 0.1GU
Tolerance: ±1.2, ±1.2% Data Port: USB
High Light:

paint gloss meter

,

60 degree gloss meter

Product Description

Touch Screen Digital Gloss Meter 60 Degree NHG60 1000gu For Car Paint Glossy Test

Touch screen gloss meter 60 degree NHG60 1000gu for car paint glossy test



Touch screen gloss meter 60 degree NHG60 1000gu for car paint glossy test



Brief Introduction


NHG60 gloss meter features with 60° angle, manufactured according to ISO2813 and GB/T 9754. It is also compatible with the standards of ASTM D523, ASTM D2457. NHG60 conforms to JJG696 first class gloss meter working requirement, corresponding with CIE 1931(2°) under CIE C light source.



NHG60 gloss meter can test material with gloss (0-1000Gu), and Now NHG60 has been widely used by our customers all over the world in many industries, like painting, lacquer, ink, coating, leather, paper, printing, plastics, electronics, furnitures, wood, decorating, ceramics, tiles, metals, hardware, marble, electroplating, package, food, cosmetics, pharmacy, cloth, garment, textiles, traffic signage, etc.



Technical Specification



Parameters Single-angle Gloss Meter NHG60
Measuring Angle

60°

Comply with Standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457

Measuring Area 60°: 9x15mm
Measuring Range 60°:0~1000GU
Division Value 0.1GU
Measurement Range Repeatability
Reproducibility
0-10GU    10-100GU    100-2000GU
± 0.1GU    ± 0.2GU       ± 0.2%GU
± 0.2GU    ± 0.5GU       ± 0.5%GU
Measurement Standard Conform to the Working Requirements for JJG696 First Class Glossmeter
Chromaticity Response Corresponding with CIE 1931(2°) under CIE C Light Source
Tolerance ±1.2, ±1.2%
Measuring Time 0.1s
Display Size TFT 3.5"
Screen-touch Yes, Capacitive Touch Screen
Data Port USB
Language Chinese, English
Battery 3200mAh Li-ion Battery , more than 10000 times (within 8 hours)
Dimension 160*75*90mm
Weight 350g
Measuring Mode&Storage

Basic Mode: 1000

Statistical Mode: 5000

Continuous Mode: 5000

PC Software GQC6 Quality Control Software with QC Report Printing Functions and More Extended Functions
Operation Temperature 0~40℃ (32~104℉)
Storage Temperature -20~50℃ (-4~122℉)
Humidity <85% Relative Humidity, No Condensation
Standard Accessories Power Adapter, USB Cable, User Manual, CD (Including QC Software), Calibration Plate
Optional Accessories Mini Printer



Frequently Asked Questions



1. Which models are the equivalent models to NHG60 Gloss Meter?

Answer: BYK4561 is the equivalent model to 3nh NHG60.
2. Are you a trader or a manufacturer?
Answer: We 3nh is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments and gloss meters. Our company and factory are located in Shenzhen which is famous for manufacturing. Welcome to visit us!
3. What's your main market.
Answer: We sell to the global market.
4. How long is your delivery time?
Answer: Generally it is 1-3 working days after the payment confirmed.
5. What is your payment terms?
Answer: The payment term is 100% T/T in advance.
6. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.



3nh nhg60 touchable glossmeter for paint with 1000gu and standard ASTM D 523
