Checkerboard Distortion Resolution Test Chart Sineimage YE006 For Checking Geometry

Place of Origin Shenzhen, China
Brand Name SineImage
Certification CE&RoHS&TUV&FCC&ISO9001
Model Number YE006
Minimum Order Quantity 1pc
Packaging Details Standard Export Package
Delivery Time within 3-5 working days after payment confirmed
Payment Terms T/T,Paypal
Supply Ability 1000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Brand SineImage Usage For Resolution And Sharpness Measurements
Light Source Can Be Equiped With Light Box Standard ISO12233(2014)
Model YE006 Diameter Center Mark 5 Mm
High Light

camera resolution chart

,

camera lens test chart

Leave a Message
Product Description



Sineimage YE006 Checkerboard Distortion Test Target T06 for checking geometry and resolution

Model YE006/T06
Type Reflective/Transparent
Size 280 x 210mm(A280&D240)
Ratio 4:3

The chessboard test chart checkerboard Distortion Test Target T06 for checking geometry and resolution is designed for checking geometry and resolution.

Data
Similar to a chessboard the test charts is composed of 13 x 18 black and white square fields which are surrounded by rectangular fields at the edges that correspond to the 14/19 grid raster lines of electronic test generators. (The division of the horizontal grid lines of these generators corresponds to 42 lines per complete picture.)

Utilization
• Checking geometry and the congruency of raster, by means of an electronically generated grid, if necessary
• Checking the uniformity of the signal generation

  distrotion test charts

Remark: We support Any customized test charts only if you have high resolution image and size.

  1.

Standard Transparent/Reflectance Test Chart Size

  1. Size Picture size(4:3) Picture size(16:9) Chart Size(16:9)
    A280 280*210mm 280*157.5mm 365*305mm
    D240 240*180mm 240*135mm 320*290mm
    D280 280*210mm 80*157.5mm 360*280mm
  2. ISO 12233 Resolution Test Chart Size
  3.
  4. Model Specification Size Material
    NQ-10-50A 0.5X 10x17.8 cm photographic paper
    NQ-10-100A 1X 20x35.6 cm photographic paper
    NQ-10-200A 2X 40x71.1 cm photographic paper
    NQ-10-400A 4X 80x142.2 cm photographic paper
    NQ-10-800A 8X 160x284.4 cm photographic paper



Remark: We support Any customized test charts only if you have high resolution image and size.
