YT4200-P3 3nh Colorimeter , Paint Color Analyzer Non Magnetic Coatings Meter Tester
Place of Origin | Shenzhen, China |
---|---|
Brand Name | 3nh |
Certification | CE, TUV, FCC, ISO9001, RohS |
Model Number | YT4200-P3 |
Minimum Order Quantity | 1 Unit |
Price | 600 |
Packaging Details | 28X24X10 cm, 1.5kg, carton box |
Delivery Time | 1-3 work days |
Payment Terms | T/T, L/C, Western Union |
Supply Ability | 1000 Units per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Model | YT4200-P3 | Measuring Range | 0-1250µm (0-1.25mm) Or 0-50mil |
---|---|---|---|
Resolution | 0.1µm (0-99.9 µm) And 1µm (over 100 µm) | Accuracy | ±1-3% (±2.5µm Or 0.1mil - Whichever The Greater) |
Minimum Measurement Area | 5mm | Minimum Sample Thickness | 0.3mm |
Meets Standards Including | ISO-2178, ISO-2360, DIN, ASTM & BS | Dimensions | 102 X 66 X 24mm |
High Light | portable spectrophotometer colorimeter,digital color meter |
Product Description
Product Description
YT4200 is a domestic coating thickness gauge manufactured by 3nh company. It can detect the thickness of various non-magnetic coatings on the magnetic metal substrate quickly and accurately. The instrument fully conforms to the magnetic test principle specified in ISO 2178, GB / T 4956, ASTM b499 and other standards. The instrument is stable, accurate and powerful. It is widely used in the manufacturing industry, metal processing industry, chemical industry and other surface engineering detection fields.
It is the basic equipment of coating surface treatment industry.
Fe based probe can detect the thickness of various non-magnetic coatings sprayed on various magnetic substrates (such as steel), such as the paint layer, powder spraying layer, porcelain coating, chromium coating, copper coating, zinc coating, etc.
It is the basic equipment of coating surface treatment industry.
Fe based probe can detect the thickness of various non-magnetic coatings sprayed on various magnetic substrates (such as steel), such as the paint layer, powder spraying layer, porcelain coating, chromium coating, copper coating, zinc coating, etc.
Specification
Model
|
YT4200-P3
|
What's in the Box?YT4200-P3
|
YT4200-P3 Gauge (Ready to Use), 1 x Calibration Checkpieces (Aluminium and Steel) &
5 x Thickness Check Foils |
Typical Users include
|
Vehicle Appraisers & Buyers, Panel Beaters / Motor Body Repairers, Painting Contractors, Galvanizers,Anodisers, Powder Coaters,
Metal Fabricators,Chromers, Motor Vehicle Manufacturers, Vehicle Detailers, Zinc Platers etc |
Ferrous Metal Mode (Fe)
(Typical Applications) |
Technology - Magnetic Induction - (enables measurement of non magnetic coatings on magnetic substrates such as Steel, Mild Steel,
Cast Iron &Magnetic Stainless Steel). Example coatings:- Paint,Zinc / Galvanising, Chrome, Copper, Enamel, Rubber, Paint, Varnish, Powder Coating, Plastic etc. |
|
|
Measuring Range
|
0-1250µm (0-1.25mm) or 0-50mil
|
Resolution
|
0.1µm (0-99.9 µm) and 1µm (over 100 µm)
|
Accuracy
|
±1-3% (±2.5µm or 0.1mil - whichever the greater)
|
Power Supply
|
2 x 1.5V AA Batteries
|
Minimum Measurement Area
|
5mm
|
Minimum Sample Thickness
|
0.3mm
|
Operating Conditions
|
Temp: 0 - 50ºC and Humidity: < 80%
|
Weight
|
99g ( including batteries)
|
Dimensions
|
102 x 66 x 24mm
|
Meets Standards Including
|
ISO-2178, ISO-2360, DIN, ASTM & BS
|
|
(suitable for laboratory and harsh field conditions)
|
Units of Measurement
(Microns & Mils) |
Metric Measurement:-
Micrometre (µm) – also known as Micron 1 µm = 1/1000mm Imperial Measurement:- Mil – also known as Thou 1 Mil = 1/1000 Inch Conversion:- 1 Mil / Thou = 25.4 Microns / Micrometre (µm) |
Additional Functionality
|
Gauge auto adjusts between Ferrous (Steel) and Non-Ferrous (Aluminium etc) Modes, Low Battery Indicator, Metric (Microns µm) or
Imperial (Mils) measurement settings, Auto Power Off, Easy Reset to Factory Settings. |
