Low Noise 36 Patch Sineimage Resolution Test Chart

  • Low Noise 36 Patch Sineimage Resolution Test Chart
  • Low Noise 36 Patch Sineimage Resolution Test Chart
Place of Origin Shenzhen China
Brand Name 3nh - SineImage
Certification CE
Model Number ITLDR36 50DB / ITWDR36 100DB / ITUHDR36 150DB
Minimum Order Quantity 1 Pcs
Price Please send inquiry
Packaging Details Safe Package
Delivery Time 1-4 Days
Payment Terms T/T
Supply Ability 1000 Pcs per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Brand 3nh/Sineimage Category Transparent
Ratio 16:9 Size Custom Designs
Name Camera Resolution Test Chart Feature High Accuracy
High Light

Sineimage Dynamic Range Test Chart

,

Reflective Camera Resolution Chart
Leave a Message
Product Description

3NH High Dynamic Range (HDR) 36 Level Test Card Transparent Test Chart




Product Description



Certificates: ISO9001:2008; CE; FCC; ROHS; TUV.



Model ITWDR36
Type Transparent
Format Custom Designs
Ratio 16:9

Brief Introduction

1. We, 3nh-Sine Image, now is the biggest and best manufacturer of Camera Test Charts in China.

2. We can make all kinds of test charts, such as ISO12233 Resolution Charts, Distortion Charts, Greyscale Charts, 18% Netral Grey Cards, SFR Charts, Dynamic Range Charts, and so on.

3. Both transmissive and reflective are OK.

4. Any customised charts are no problem, either.

5. Our test charts definitely can match with the charts of ESSER(IE) and Imatest, no matter in accuracy or in quality.
6. Compared with ESSER(IE) and Imatest, our advantages exist on not only the much better prices but also much better delivery time.

7. More and more world famous companies have already trusted us as their long-term supplier for camera test charts.
8. These companies include HUAWEI, Apple, OPPO, vivo, O-film, DJI, GoPro, Lenovo, Samsung, LG, Suny Optics, ZTE.

9. We can make some small samples for you to check and confirm first.




36

This Sineimage 36-Patch Dynamic Range Test Chart Transparent has 36 low-noise density patches with density steps of approximately 0.1, for a density range of at least 3.2 (density from base to base + 3.1 minimum). A nearly circular patch arrangement ensures that vignetting has minimal effect on results. A CSV reference file with actual densities will be supplied. The chart has an active area of 197x235 mm (7.75x9.25 inches) on 203x254 mm (8x10 inch) film.

It also contains slanted edges in the center and corners with 4:1 contrast for measuring MTF. The edges have an MTF50 >= 16 cycles/mm, which is about 3 times better than the best inkjet charts. Registration marks make the regions easy to select. A neutral gray background helps ensure that the chart will be well-exposed in auto exposure cameras (compared to charts with black backgrounds, which are sometimes strongly overexposed).

It is supported by Stepchart, Multicharts, Multitest and can be used with the Dynamic Range postprocessor if several manual exposures are available. Dmax >= 3.4 is sufficient for camera phones and digital cameras with small pixel sizes, but high-end DSLRs generally have higher dynamic ranges (and also manual exposure), which makes them well suited for Dynamic Range.

This chart is produced with a high-precision LVT film recording process for the best possible density range, low noise, and fine detail.





Related Products:



1. ISO Camera Test Chart

24 Colors ColorChecker





The following is a complete product line:



Model Specification Size Material
NQ-10-50A 0.5X 10x17.8 cm photographic paper
NQ-10-100A 1X 20x35.6 cm photographic paper
NQ-10-200A 2X 40x71.1 cm photographic paper
NQ-10-400A 4X 80x142.2 cm photographic paper
NQ-10-800A 8X 160x284.4 cm photographic paper


ENHANCED ISO 12233 RESOLUTION TEST CHART



Specification Active Area Material

1 X - 20 cm x 35.6 cm Photographic Paper

2 X - 40 cm x 71.1 cm Photographic Paper

4 X - 80 cm x 142.2 cm Photographic Paper

8 X - 160 cm x 284.4 cm Photographic Paper

0.5X - 10cm x 17.8 cm Photographic Paper




Remark: We support Any customized test charts only if you have high resolution image and size.



3. TE248 A Distortion Grid Reflectance



24 Colors ColorChecker



4. Distortion Grid Test Chart To Measure Disortion of Digital Cameras



24 Colors ColorChecker



5.ITE Grayscale Chart / Grey Scale with 11 Patched(Y=0.45)



24 Colors ColorChecker



This iso camera test chart is used to measure sharpness from slanted-edge patterns (as Spatial Frequency Response = SFR) using the Imatest SFR module. It can also measure resolution from the hyperbolic wedges using the Imatest Wedge module (a part of Rescharts).





Company Information

Shenzhen 3nh Technology Co., Ltd. is a high-tech company who specializes in researching and developping, designing and manufacturing testing and measuring instruments and equipment. We have owned a 19 years accumulation of technology and experience in color and gloss management field, since founded in 1998.
company detail

FAQ



FAQ

1. Are you the manufacturer ?

Yes, we are the manufacturer of the camera testing equipments,we also can sell the chart from other brand.

2. Could you can make OEM test chart?

Yes, according to your requirements, we can make any OEM test charts with different size.

3. Could you can make any chart from other brand?

Yes, just give us the model No. or picture about the chart.

4. Is it expensive?

Of course not. You will be surprise about the price we give you.

5.Delivery Time?

Talior-made chart: 1-2 weeks after payment; Normally Chart: 2-5 working days after apyment.

6.Why choose us?

Professional company, professional team, professional technician,professional machine, high quality low price.
