4mm Aperture CIE Lab Precision Colorimeter 3NH NR110

4mm Aperture CIE Lab Precision Colorimeter 3NH NR110
4mm Aperture CIE Lab Precision Colorimeter 3NH NR110

Large Image :  4mm Aperture CIE Lab Precision Colorimeter 3NH NR110

Product Details:

Place of Origin: Shenzhen, China
Brand Name: 3nh
Certification: CE, TUV, FCC, ISO9001, RohS
Model Number: NR110

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit
Price: Discuss
Packaging Details: 46*25*38cm, 4.5kg, Alluminum Box
Delivery Time: 1-3 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 Units per Month
Detailed Product Description
Measuring Aperture: Φ4mm Repeatability: Within ΔE*ab 0.08
Illuminating/Viewing Geometry: 8° / D Measuring Range: L: 0 To 100
Illuminant Device: LED Blue Light Excitation Storage: 100 Pcs Standard Samples; 20000 Pcs Test Samples
Color Difference Formula: ΔE*ab; ΔL*ab; ΔE*C*H Measuring Conditions: CIE 10° Standard Observer
High Light:

CIE Lab Precision Colorimeter

,

4mm Aperture Lab Precision Colorimeter

,

3NH NR110 Colorimeter

Precision Colorimeter 3NH NR110 with 4mm aperture CIE lab color space

Product Description






1 4mm aperture
2 Accuracy: delta E 0.08
3 Illuminant: D65
4 Li-ion battery



3nh Brand Color Meter / Colorimeter Price Manufactuer Features



1. Double Locating: Illuminating locating and cross locating

2. Double Measurement End Face: Large area measurement and small area measurement

3. New Integrating Sphere Design: More stable measurement

4. Equipped with Rechargeable High-Capacity Li-ion Battery



3nh Brand Color Meter / Colorimeter Price Manufactuer Specifications



Illuminating/Viewing Geometry 8/d
Measuring Aperture Φ4mm
Detector Silicon photoelectric diode
Locating Illuminating Locating/Cross Locating
Measurement End Face Large stable end-face and small concave-convex end-face
Color Space

CIEL*a*b*C*h* CIEL*a*b*

CIEXYZ

Color Difference Formula delta E*ab delta L*a*b* E*C*h*
Light Source D65
Light Source Device LED blue light excitation
Errors Between Each Equipment ≤0.80 delta E*ab
Storage 100pcs standards 20000pcs samples
Repeatability

Standard deviation within E*ab 0.08

Average of 30 measurements of standard white plate

Language English/Chinese
Weight 450g
Dimension 205×67×80 mm
Power source Rechargeable lithium-ion battery 3.7V@3200mAh
Lamp Life 3 years, more than 1.6 million measurements
Charging Time 8 hours--100% electricity
PC Software CQCS3 Software
Printer (optional) Miniature thermal printer





NR110-1

4mm Aperture CIE Lab Precision Colorimeter 3NH NR110 14mm Aperture CIE Lab Precision Colorimeter 3NH NR110 24mm Aperture CIE Lab Precision Colorimeter 3NH NR110 3



3nh Brand Color Meter / Colorimeter Price Manufactuer






Illuminating Locating, Cross Locating, Large Stable End Face, Small Concave-Convex End Face. (for NR110 Precise Colorimeter )








Certifications

ISO 9001, CE, ROHS, FCC, TUV, SCM CERTIFICATES

CERTIFICATE 6



Company Information

3nh & tilo is a very professional manufacturer from China for 22 years, and mainly produces colorimeter, spectrophotometer, color density meter, gloss meter, color light box, color proof table, coating thickness gauge, iso test chart, etc.

Our Certificates:
ISO9001; CE; FCC; ROHS; TUV; SCM.

The parameters of test results are integrating with international standards. Our products are exported around the world. We can provide customization service which has been well received by customers.

20200707114603



Other products:



YS3060 Grating spectrophotometer
3nh brand YS3060 ral color chart powder test spectrophotometer with powder test box d/8 SCE SCI 8mm 4mm aperture

NHG268 tri gloss meter
3nh brand YS3060 ral color chart powder test spectrophotometer with powder test box d/8 SCE SCI 8mm 4mm aperture

P60+ Tilo color light box
3nh brand YS3060 ral color chart powder test spectrophotometer with powder test box d/8 SCE SCI 8mm 4mm aperture

Warranty:

3nh Brand Color Meter / Colorimeter Price Manufactuer is under warranty for 12 months from the purchase date. Customers must provide warranty card and valid proof of purchase.
