Product Details:
Payment & Shipping Terms:
|
| Measuring Aperture: | Φ4mm & 8mm | Repeatability: | Within ΔE*ab 0.03 |
|---|---|---|---|
| Illuminating/Viewing Geometry: | 8° / D | Measuring Range: | L: 0 To 100 |
| Illuminant Device: | LED White Light | Storage: | 100 Pcs Standard Samples; 10000 Pcs Test Samples |
| Color Difference Formula: | ΔE*ab; ΔL*ab; ΔE*C*H | Measuring Conditions: | CIE 10° Standard Observer |
| High Light: | 3NH NR100 Handheld Colorimeter,CIE 10° Handheld Colorimeter,8mm Aperture Portable Spectrophotometer Colorimeter |
||
3NH NR100 Precision Colorimeter
NR100 Precision Colorimeter
3nh R&D team concentrates on customer needs and develops a high precision & low cost portable colorimeter NR100. This new model NR100 features with two apertures Φ8mm flat aperture and Φ4mm tip aperture, suitable for most samples use. With color space CIE LAB, NR100 is good to check color difference for delta E, and widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, industries, scientific research institutes, schools and laboratories.
NR100 Colorimeter Technical Specifications
| Model | NR100 |
| Illuminating/Viewing Geometry | 8/d(8°illumination angle/diffuse viewing); Conforms to CIE No.15,GB/T 3978. |
| Illumination | LED white light |
| Detector | Silicon photoelectric diode |
| Measuring Aperture | Φ8mm flat aperture; Φ4mm tip aperture |
| Color Space | CIE LAB |
| Color Difference Formula | ΔE*ab |
| Observer Angle | CIE 10° |
| Light Source | D65 |
| Displayed Data | Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset |
| Measuring Time | 1.0s |
| Repeatability | Standard deviation within ΔE*ab 0.03 (Average of 30 measurements of standard white plate) |
| Errors Between Each Equipment | Within ΔE*ab 0.4 (Average for 12 BCRA Series II color tiles) |
| Dimension | 205×67×80 mm |
| Weight | 500g |
| Power source | Rechargeable lithium-ion battery 3.7V@3200mAh |
| Lamp Life | TFT 2.8 inch |
| Interface | USB |
| Data Memory | 100pcs standards 10000pcs samples |
| Operating Environment | 0~40℃(32~104°F) |
| Storage Environment | -20~50℃(-4~122°F) |
| PC Software | No |
| Standard Accessory | Power Adapter, User Guide, Wristbands, Φ8mm flat aperture; Φ4mm tip aperture. |
| Optional Accessory | Micro Printer, powder test box |
| Notes: The specifications are subject to change without notice. | |
| Size | 45*23*38cm |
| Gross weight | 3kg |
| Standard accessory | Power Adapter, User Guide, Wristbands, Φ8mm flat aperture; Φ4mm tip aperture. |
| Optional accessory | micro printer, power test box |
We can ship by DHL, Fedex, UPS, TNT, SF express etc door to door, and we support 1 year warranty except consumables.
Shenzhen 3nh Technology Co., Ltd. is a high-tech enterprise. We research, develop, produce and market photoelectric detection products in photoelectric detection technology field and color management field.
Our Certificates:
ISO9001:2008; CE; FCC; ROHS; TUV.
The parameters of test results are integrating with international standards. Our products are exported around the world. We can provide customization service which has been well received by customers.
Frequently Asked Questions
1. Are you a trader or a manufacturer?
Answer: We 3nh is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments and gloss meters. Our company and factory are located in Shenzhen which is famous for manufacturing. Welcome to visit us!
2. What's your main market.
Answer: We sell to the global market.
3. How long is your delivery time?
Answer: Generally it is 1-3 working days after the payment confirmed.
4. What is your payment terms?
Answer: The payment term is 100% T/T in advance.
5. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.
