LED White Light Paint Matching Spectrophotometer NR100 3nh For Distributor Supplier

Place of Origin Shenzhen, China
Brand Name 3nh
Certification CE&RoHS&TUV&FCC&ISO9001
Model Number NR100
Minimum Order Quantity 1pc
Packaging Details Standard Export Package
Delivery Time 2 work days
Payment Terms T/T,Paypal
Supply Ability 1000PCS/MONTH
Product Details
Model NR110 Illuminating/Viewing Geometry 8/d
Illumination LED White Light Detector Silicon Photoelectric Diode
Measuring Aperture Φ8mm Flat Aperture; Φ4mm Tip Aperture Color Space CIEL*a*b
Light Source D65 Dimension 205×67×80 Mm
High Light

hunter lab spectrophotometer

,

color measurement instruments

Leave a Message
Product Description

NR100 wholesale 3nh Cheap Colorimeter for Distributor Supplier



Brief Introduction:

NR100 is a high-cost performance handheld colorimeter, and easy to use. It is widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, industries, scientific research institutes, schools and laboratories.



With two apertures, NR100 colorimeter is suitable for most samples to check color difference. 8mm flat aperture is good used to measure large plane samples while 4mm tip aperture is used to measure small objects with concave surfaces. It is easy to use, and can meet the customer's routine testing needs.



Product Advantages:

  • Built-in white plate parameters. No need to calibrate each time which realize rapid measurement;
  • Double Apertures: Φ8mm flat aperture and Φ4mm tip aperture for switch, easy to measure concave sample in large plane;
  • High stability and accuracy, good compatibility for test data compared with geometric optical structure D/8 spectrophotometer;
  • Double locating: illuminating locating and cross locating;
  • Equipped with rechargeable built-in high-capacity Li-ion battery. No need to purchase battery repeatedly;
  • True color FTF 2.8 inch display, good human-computer interaction;
  • More than 10,000 test data storage spaces;
  • The new integral sphere design makes the measurement more stable.



NR100 Colorimeter Technical Specifications:



Model NR100
Illuminating/Viewing Geometry 8/d(8°illumination angle/diffuse viewing); Conforms to CIE No.15,GB/T 3978.
Illumination LED white light
Detector Silicon photoelectric diode
Measuring Aperture Φ8mm flat aperture; Φ4mm tip aperture
Color Space CIE LAB
Color Difference Formula ΔE*ab
Observer Angle CIE 10°
Light Source D65
Displayed Data Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset
Measuring Time 1.0s
Repeatability Standard deviation within ΔE*ab 0.03 (Average of 30 measurements of standard white plate)
Errors Between Each Equipment Within ΔE*ab 4
(Average for 12 BCRA Series II color tiles)
Dimension 205×67×80 mm
Weight 500g
Power source Rechargeable lithium-ion battery 3.7V@3200mAh
Lamp Life TFT 2.8 inch
Interface USB
Data Memory 100pcs standards 10000pcs samples
Operating Environment 0~40℃(32~104°F)
Storage Environment -20~50℃(-4~122°F)
PC Software No
Standard Accessory Power Adapter, User Guide, Wristbands, Φ8mm flat aperture; Φ4mm tip aperture.
Optional Accessory Micro Printer, powder test box
Notes: The specifications are subject to change without notice.
