MDF Wood Colour Assessment Cabinet Lightweight Color Viewing Light Booth P60+
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Standard | ASTM D1729, ISO3664, DIN, ANSI And BSI | Color | N7 Grey |
|---|---|---|---|
| Material | MDF Wood | Light Source | D65, TL84, CWF, TL83/U30, F, UV |
| Voltage | 220V/110V | Overall Size | 695*552*502mm |
| High Light | color matching cabinet,color checking light box,MDF Wood Colour Assessment Cabinet |
||
Product Description
TILO P60+ 6 Light Source D65 TL84 UV F CWF TL84 Colour Check Machine Color Assessment Cabinent
P60+ color light box can be applied to the industries that need to perform color difference testing as follows: as the premiere designer and manufacturer of color matching instrument products for the Graphic arts, Photographic, Textile, Dyeing, Packaging, Printing, Leather, Inks, Knitwear, Plastic, Automotive and Ceramics industries.
Features
Light Source: D65, TL84, UV, F, CWF, TL83
Overall Size: 695*552*502mm
Export wooden case dimension:77*63*27cm
Voltage: 220V/110V
Net Weight:19.5KG
Gross Weight:38KG
Remarks: Optional tubes D50, D75, U30,TL83, U35, A
Light Source Parameter
| Light Source | Quantity |
| D65 18w/965 | 2 pcs |
| TL84 18w/84 | 2 pcs |
| UV | 1 pcs |
| F | 6 pcs |
| CWF 18w/33 | 2 pcs |
| TL83 18w/830 | 2 pcs |
Packing List:
| No. | Name | Quantity |
| 1 | Light Booth Top Cover | 1 pcs |
| 2 | Light Booth Bottom | 1 pcs |
| 3 | Light Booth Back Cover | 1 pcs |
| 4 | Light Booth Side Cover | 2 pcs |
| 5 | Power Adapter | 1 pcs |
| 6 | Operating Manual | 1 pcs |
| 7 | Warranty Card | 1 pcs |
| 8 | D65 Light Tube | 2 pcs |
| 9 | TL84 Light Tube | 2 pcs |
| 10 | UV Light Tube | 1 pcs |
| 11 | F Light Tube | 4 pcs |
| 12 | CWF Light Tube | 2 pcs |
| 13 | TL83 Light Tube | 2 PCS |
Remarks: Optional tubes D50, D75, U30,TL83, U35, A. If you need, please let us know your detail requirement.
