Simple Digital Gloss Meter CIE C Light Source Concise Appearance With 3.5 Inch Screen
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model | HG60S | Measuring Angle | 60 |
|---|---|---|---|
| Measuring Area | 9*15 | Division Range | 0-200GU |
| Repeatability | ±1GU | Weight | 350g |
| Display | TFT 3.5 Inch | Basic Mode | 1000 |
| Highlight | paint gloss meter,portable gloss meter |
||
Product Description
HG60S Economic Gloss Meter Simple Glossmeter 0-200GU with 3.5 inch screen
Brief Introduction:
HG60S gloss meter features with 60° angle, manufactured according to ISO2813 and GB/T 9754. It is also compatible with international standards of ASTM D523, ASTM D2457. HG268 conforms to JJG696 first class gloss meter working requirement, corresponding with CIE 1931(2°) under CIE C light source.
HG60S gloss meter is widely used to test glossiness in these industries, such as automobile, paint, ink, stoving varnish, coating, wood products; marble, granite, vitrified polished tile, pottery brick and porcelain; plastic, paper; hardware industries, etc.
Features:
- 60° angle for semi gloss
- Concise appearance, feel good
- Display 5 sets of measurement data, good for comparison
- Built-in lithium ion rechargeable battery
- Basic model measurement can meet basic glossiness testing requirements
- One button for all angles measurement at the same location
- Comply with international standards
- Stable performance, easy to read data.
Specifications:
| HG60S Economic Gloss Meter | |
| Model: | HG60S |
| Measuring Angle | 60° Comply with standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457 |
| Measuring Area (mm) | 9x15 |
| Measuring Range | 0~200GU |
| Division Value | 1GU |
| Measurement Range Repeatability Reproducibility | 0-200GU ±1GU ± 1GU |
| Measurement Standard | Conform with JJG696 first class glossmeter working requirement |
| Chromaticity Corresponding | Corresponding with CIE 1931(2°) under CIE C light source |
| Errors | ±1.5 , ± 1.5% |
| Measuring Time | 0.5s |
| Dimension | L*W*H : 160mm*75mm*90mm |
| Weight | 350g |
| Language | Chinese/English |
| Battery | 3200mAh Li-ion Battery, >10000 times(within 8 hours) |
| Display | TFT 3.5 inch |
| Interface | USB/RS-232 |
| Storage | / |
| Software | / |
| Operation Temperature | 0~40℃(32~104°F) |
| Storage Temperature | -20~50℃(-4~122°F) |
| Humidity | <85% relative humidity, no condensation |
| Standard Accessories | Power Adapter, USB cable, User Manual, Calibration Plate |
| Optional Accessories | Miniature Printer |
| Note | The specifications are subject to change without notice. |
