Surface Gloss Tester Digital Gloss Meter 20 60 85 Three Measuring Angles Durable

  • Surface Gloss Tester Digital Gloss Meter 20 60 85 Three Measuring Angles Durable
Place of Origin Shenzhen,China
Brand Name 3nh
Certification CE,RoHs,ISO,ASTM etc.
Model Number YG268
Minimum Order Quantity 1pc
Packaging Details Standard Export Package
Delivery Time 2 work days
Payment Terms T/T,Paypal
Supply Ability 1000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model YG268 Measuring Angle 20 60 85
Division Value 0.1GU Measuring Range 0-2000GU
Measuring Modes Basic Mode; Statistic Mode; Continuous Mode; QC Mode Repeatability 0~100GU : ±0.2GU; 100~2000GU : ±0.2%GU
Language Chinese And English Software GQC6
High Light

paint gloss meter

,

60 degree gloss meter
Leave a Message
Product Description

Factory price 20 60 85 three measuring angles gloss meter for granite paint plastic, surface gloss tester



Brief Introduction:



YG268 gloss meter features with 20° 60° 85° angle, manufactured according to ISO2813 and GB/T 9754. It is also compatible with international standards of ASTM D523, ASTM D2457. YG268 conforms to JJG696 first class gloss meter working requirement, corresponding with CIE 1931(2°) under CIE C light source.





Features:



  • 20° 60° 85° angle for semi gloss;
  • with auto-calibration function;
  • elegant design combined with aesthetics and ergonomics;
  • large storage to save over 35000 data;
  • Meet the first grade requirements of JJG696;
  • Connect to PC, more extend functions
  • One button for all angles measurement at the same location
  • Comply with international standards
  • Stable performance, easy to read data.
  • can realize auto power on & off automatically within 30s-120s



Specifications:



YG Series Specification Parameter

Model

YG60S 60°Economic Gloss Meter

YG60 60°Accurate Gloss Meter

YG268 Tri-angle Gloss Meter

Measuring Angle

60°

60°

20° 60°85°

Measuring Area

60°: 0-200GU

60°: 0-1000GU

20°: 0-2000GU

60°: 0-1000GU

85°: 0-160GU

Division Value

1GU

0.1GU

Measuring Modes

Basic mode

Basic mode; Statistic mode; Continuous mode; QC mode

Measuring Time

0.5S

Repeatability

0~100GU : ±0.5GU; 100~2000GU : ±0.5%GU

0~100GU : ±0.2GU; 100~2000GU : ±0.2%GU

0~100GU : ±0.2GU; 100~2000GU : ±0.2%GU

Accurate

Conform with JJG696 second grade requirements of gloss meter

Conform with JJG696 first grade requirements of gloss meter

Auto Power-off Time

30s

Within 30s-120s

Long-time Calibration

/

Automatically check and made the calibration

Language

Chinese & English

Storage

/

35000(Basic mode &Statistic mode : 1500; Continuous mode : 10000; QC mode: 10000)

Display

2.3 inch white and black screen

Size

160*52*84mm

Weight

About 300g

Power Supply

1pc dry-cell battery(can measure 10000 times) or use USB Charge

Interface

USB

USB & Bluetooth 2.1 version

PC Software

/

GQC6 QC software can printing testing report and with more extended functions

Operation Temperature Range

0-40℃(32-104° F)

Storage Temperature Range

-20-50℃(-4-122° F)

Humidity Range

< 85% RH, without condensation

Standard Accessories

User manual, calibration plate

USB cable, user manual, calibration plate, QC software

Optional Accessories

Miniature printer

Notification: the technical parameter is only for reference





GQC6 Software Introduction:



GQC6 software is used with 3nh gloss meter for PC connection, measurement, data management, data export, print reports, etc.



Application:



YG268 gloss meter is widely used to test glossiness in these industries, such as automobile, paint, ink, stoving varnish, coating, wood products; marble, granite, vitrified polished tile, pottery brick and porcelain; plastic, paper; hardware industries, etc.Surface Gloss Tester Digital Gloss Meter 20 60 85 Three Measuring Angles Durable 0
