Low Glossy 60 Degree 300gu Gloss Level Meter 9x15mm Measuring Area HG60 With PC Software
Product Details
| Measuring Angle: | 60° | Measuring Area(mm): | 60°:9x15 |
|---|---|---|---|
| Measuring Range(GU): | 60°: 0~300 | Division Value: | 0.1GU |
| Tolerance: | ±1.5, ±1.5% | Data Port: | USB |
| Highlight |
paint gloss meter,60 degree gloss meter |
||
Product Description
Low Glossy 60 Degree Economic Gloss Meter 300gu Gloss Level Meter 9x15mm Measuring Area HG60 Silk with PC Software
Technical Specification
| Parameters | Single-angle Gloss Meter HG60 |
| Measuring Angle |
60° Comply with Standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457 |
| Measuring Area | 60°: 9x15mm |
| Measuring Range | 60°:0~300GU |
| Division Value | 0.1GU |
| Measurement Range Repeatability Reproducibility |
0-10GU 10-100GU 100-300GU ± 0.1GU ± 0.2GU ± 0.2%GU ± 0.2GU ± 0.5GU ± 0.5%GU |
| Measurement Standard | Conform to the Working Requirements for JJG696 First Class Glossmeter |
| Chromaticity Response | Corresponding with CIE 1931(2°) under CIE C Light Source |
| Tolerance | ±1.5, ±1.5% |
| Measuring Time | 0.1s |
| Display Size | TFT 3.5" |
| Screen-touch | Yes, Capacitive Touch Screen |
| Data Port | USB |
| Language | Chinese, English |
| Battery | 3200mAh Li-ion Battery , more than 10000 times (within 8 hours) |
| Dimension | 160*75*90mm |
| Weight | 350g |
| Measuring Mode&Storage |
Basic Mode: 1000 |
| PC Software | GQC6 Quality Control Software with QC Report Printing Functions and More Extended Functions |
| Operation Temperature | 0~40℃ (32~104℉) |
| Storage Temperature | -20~50℃ (-4~122℉) |
| Humidity | <85% Relative Humidity, No Condensation |
| Standard Accessories | Power Adapter, USB Cable, User Manual, CD (Including QC Software), Calibration Plate |
| Optional Accessories | Mini Printer |
Brief Introduction
1. HG60 one angle simple glossmeter, whose complete proprietary intellectual property rights are fully owned by Silk, was researched and developped complying with the international standard ISO2813 and China national standard GB/T9754, also the standard ASTM D 523 and ASTM D 2457.
2. As the whole world's first glossmeter which is with a ultra-large display, HG60 features the accurate measurement, simple operation and stable performance. 5 groups of data can be displayed on screen simultaneously, easy to compare. The standard data value can be manually input.
3. HG60 has one measuring mode. Basic Mode, the simplest sample measurement mode, which makes it easy to operate.
4. Now HG60 has been widely used by our customers all over the world in many industries, like painting, lacquer, ink, coating, leather, paper, printing, plastics, electronics, furnitures, wood, decorating, ceramics, tiles, metals, hardware, marble, electroplating, package, food, cosmetics, pharmacy, cloth, garment, textiles, traffic signage, etc.
Frequently Asked Questions
1. Which models are the equivalent models to HG60 Gloss Meter?
Answer: BYK4561 is the equivalent model to Silk HG60, they share the very close measured values.
2. Are you a trader or a manufacturer?
Answer: We Silk is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments and gloss meters. Our company and factory are located in Beijing which is famous for manufacturing. Welcome to visit us!
3. What's your main market.
Answer: We sell to the global market.
4. How long is your delivery time?
Answer: Generally it is 1-3 working days after the payment confirmed.
5. What is your payment terms?
Answer: The payment term is 100% T/T in advance.
6. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.
