Star Target Back Focus Test Chart SineImage Optical focus YE0220 For Camera Lenses

Name: Star Target Back Focus Test Chart SineImage Optical focus YE0220 For Camera Lenses
Brand: Beijing Silk Road Enterprise Management Services Co., Ltd.
SKU: YE0220
Price: 200 USD
Availability: InStock

Brand Name: SineImage

Model Number: YE0220

Place of Origin: China

Certification: CE&RoHS&TUV&FCC&ISO9001

Minimum Order Quantity: 1pc

Price: 200 usd

Supply Ability: 1000pcs/month

camera lens test chart

camera resolution chart

camera test chart

Product Details

Brand:	SineImage	Usage:	Transmission Characteristics Of 8K Camera
OEM:	Yes	Light Source:	Can Be Equiped With Light Box
D:	0.75	Transmission:	18%
Model:	TE278
Highlight	camera resolution chart , camera lens test chart

Product Description

SineImage YE0220 Back Focus Test Chart for Camera Lenses

Model	YE0220
Type	Reflectance/Transparent
Format	Custom Designs
Ratio	4:3
Material	Film or HD photographic paper

The Sineimage YE0220 back focus test chart is designed for adjustment of camera lenses and checking back focal distance. It consists of a large Siemens star in the center an four smaller ones positioned in the corners of the test chart.

With the aid of a low transmission filter and by means of low level lighting make sure that the camera is not over modulated with the aperture in the open position.

a) Optical focus: Adjust focus at shortest focal length.

b) Back focal distance (lens): Adjust focus at shortest focal length by regulating lens mechanically with adjustment screw and optimize alternatively with a).

c) Back focal distance (pick-up tubes): If focus varies from channel to channel between greatest and shortest focal length, the individual pick-up tubes must be adjusted mechanically in the optical axis.

1. Select white channel. Set optical focus at greatest focal length. With shortest focal length and divergent f ocus adjust the pick-up tube in W-channel until optimum focus is achieved. If necessary optimize by alternating with optical focus adjustment.

2. With unchanged optical focus adjustment and shortest focal length adjust the red and blue pick-up tube until optimum focus is achieved. Image focus (focus adjustment) is maintained at all focal lengths (zoomin) and constant distance from object by means of back focal distance adjustment.

Remark: We support Any customized test charts only if you have high resolution image and size.

Frequently Asked Questions:

1. Are you a trader or a manufacturer?
Answer: We Silk is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments, gloss meters and camera test charts. Our company and factory are located in Beijing which is famous for manufacturing. Welcome to visit us!
2. What's your main market.
Answer: We sell to the global market.
3. How long is your delivery time?
Answer: Generally it is 3-7 working days after the payment confirmed.
4. What is your payment terms?
Answer: The payment term is 100% T/T in advance.
5. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.
