Color Checker Resolution Test Chart Photography Color Bar Test Sineimage YE0106
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Brand | SineImage | Usage | For Resolution And Sharpness Measurements |
---|---|---|---|
Light Source | Can Be Equiped With Light Box | Standard | ISO12233(2014) |
Model | YE0106 | Diameter Center Mark | 5 Mm |
High Light | camera resolution chart,camera lens test chart |
Product Description
Sineimage YE0106 color checker photography Color Bar Test Chart -Transparency
The YE0106 color checker test chart is designed for checking the color rendition of TV cameras. The picture area is divided into six color bars showing the three primary colors red, green and blue and the secondary colors cyan, yellow and purple; in addition there i
The YE0106 test chart is designed for checking the color rendition of TV cameras. The picture area is divided into six color bars showing the three primary colors red, green and blue and the secondary colors cyan, yellow and purple; in addition there is one bar of white and black. The succession corresponds to that of an electronically generated color bar.
Color | Transparent | Yellow | Cyan | Green | Magenta | Red | Blue |
---|---|---|---|---|---|---|---|
Density | 0.08~1.0 | 1.4~2.0 | 0.9~1.3 | 1.95~2.35 | 1.1~1.5 | 1.8~3.0 | 0.8~1.2 |
Effective Area | Outer Size | |
---|---|---|
4:3 | 245×175 | 320×290 |
16:9 | 272×153 | 310×200 |
Standard Transparent/Reflectance Test Chart Size
-
Size Picture size(4:3) Picture size(16:9) Chart Size(16:9) A280 280*210mm 280*157.5mm 365*305mm D240 240*180mm 240*135mm 320*290mm D280 280*210mm 80*157.5mm 360*280mm - ISO 12233 Resolution Test Chart Size
-
Model Specification Size Material NQ-10-50A 0.5X 10x17.8 cm photographic paper NQ-10-100A 1X 20x35.6 cm photographic paper NQ-10-200A 2X 40x71.1 cm photographic paper NQ-10-400A 4X 80x142.2 cm photographic paper NQ-10-800A 8X 160x284.4 cm photographic paper
