Digital Camera Resolution Test Chart Transparent USAF 1951 Target Standard
Product Details
| Brand: | SineImage | Model: | TE250D |
|---|---|---|---|
| Light Source: | Can Be Equipment Standard Light Source | Standard: | USAF 1951 |
| Type: | Optical LCD Vision Chart | Brightness: | 250 Cd/m2 |
| Highlight |
camera resolution chart,camera lens test chart |
||
Product Description
TRANSPARENT USAF 1951 TARGET Standard Camera Test Chart
The target is high contrast transparency containing group 0 to 7 on a 35 mm film. The single patterns in the groups are based on 3 black bars on white ground. These pattern are existing in horizontal and in vertical direction. The structure corresponds to the USAF 1951 standard.
The frequencies are listed in the table below.
| Group Number | 0 | 1 | 2 | 3 | ||||
|
Element |
Linepair / mm |
equivalent Ppi |
Linepair / mm |
Equivalent Ppi |
Linepair / mm |
equivalent Ppi |
Linepair / mm |
equivalent Ppi |
| 1 | 1,00 | 50,80 | 2,00 | 101,60 | 4,00 | 203,20 | 8,00 | 406,40 |
| 2 | 1,12 | 56,90 | 2,24 | 113,79 | 4,49 | 228,09 | 8,98 | 456,18 |
| 3 | 1,26 | 64,01 | 2,52 | 128,02 | 5,04 | 256,03 | 10,10 | 513,08 |
| 4 | 1,41 | 71,63 | 2,83 | 143,76 | 5,66 | 287,53 | 11,30 | 574,04 |
| 5 | 1,59 | 80,77 | 3,17 | 161,04 | 6,35 | 322,58 | 12,70 | 645,16 |
| 6 | 1,78 | 90,42 | 3,56 | 180,85 | 7,13 | 362,20 | 14,30 | 726,44 |
| Group Number | 4 | 5 | 6 | 7 | ||||
|
Element |
Linepar / mm |
equivalent Ppi |
Linepar / mm |
equivalent Ppi |
Linepar / mm |
equivalent Ppi |
Linepair / mm |
Equivalent Ppi |
| 1 | 16,00 | 812,80 | 32,00 | 1625,60 | 64,00 | 3251,20 | 128,00 | 6502,40 |
| 2 | 17,95 | 911,86 | 36,00 | 1828,80 | 71,80 | 3647,44 | 144,00 | 7315,20 |
| 3 | 20,16 | 1024,13 | 40,30 | 2047,24 | 80,60 | 4094,48 | 161,00 | 8178,80 |
| 4 | 22,62 | 1149,10 | 45,30 | 2301,24 | 90,50 | 4597,40 | 181,00 | 9194,80 |
| 5 | 25,39 | 1289,81 | 50,80 | 2580,64 | 102,00 | 5181,60 | 203,00 | 10312,40 |
| 6 | 28,50 | 1447,80 | 57,00 | 2895,60 | 114,00 | 5791,20 | 228,00 | 11582,40 |
