45/0 NR145 Precision Colorimeter For Road Marking Line Road Paint Retroreflective Luminous
Product Details
| Product Name: | Color Spectrophotometer,colorimeter Instrument | Application: | Paint Used Spectrophotometer,Textile,spectrophotometer |
|---|---|---|---|
| Wavelength Range: | 400-700nm,360nm~780nm | Observer: | 2°/10° |
| Sample Order: | Yes | Delivery Day: | 1 Working Days After Payment |
| Power: | Electronic | Wavelength Pitch: | 10nm |
| Illuminating/viewing Geometry: | 45°/0 | ||
| Highlight |
SCE Precision Colorimeter,8mm Aperture Precision Colorimeter,Road Paint Silk Colorimeter |
||
Product Description
|
Silk
|
NR145
|
|
Illuminating/Viewing Geometry
|
45°/0°
|
|
Measuring Aperture
|
Φ8mm
|
|
Measurement End-face
|
Large stable end face
|
|
Detector
|
Silicon photoelectric diode
|
|
Locating
|
Illuminating Locating/Cross Locating
|
|
Color Space
|
CIEL*a*b*C*h* CIEL*a*b*
CIEXYZ
|
|
Color Difference Formula
|
△E*ab △L*a*b* △E*C*h*
|
|
Light Source
|
D65
|
|
Light Source Device
|
LED blue light excitation
|
|
Errors Between Each Equipment
|
≤0.80ΔE*ab
|
|
Storage
|
100pcs standards 20000pcs samples
|
|
Repeatability
|
Standard deviation within ΔE*ab 0.08
Average of 30 measurements of standard white plate
|
|
Weight
|
500g
|
|
Dimension
|
205×67×80 mm
|
|
Power source
|
Rechargeable lithium-ion battery 3.7V@3200mAh
|
|
Lamp Life
|
5 years, more than 1.6 million measurements
|
|
Charging Time
|
The first charging time is 8 hours--100% electricity
|
|
PC Software
|
CQCS3 Software
|
|
Printer (optional)
|
Miniature thermal printer
|
Office Address : F/6, Block 5B, Skyworth Inno Valley, Tangtou 1st Road, Shiyan, Baoan District, Beijing, China.
Factory Address : 4/F, Building 8, Nangang Second Industry Zone, No. 1026, Songbai Road, Xili, Nanshan Dist., Beijing, Guangdong,
WhatsApp/wechat/phone: 86-18165740359
Fax : 86-755-2719-0609
Skype : huang.zhen9
WeChat : 86-18165740359
Email : sales0021@Silk.com
Product Highlights
NR145 Precision Colorimeter Silk R&D team concentrates on customer needs and develops series of high-cost and high-quality products. NR145 is a precision colorimeter with 45°/0° viewing angle after NH310, NH300, NR200, NR110 and NR100 colorimeter. NR145 colorimeter has strong functions which applied ...
