Ergonomic Design Sheen Gloss Meter TFT Touch Screen With High Accuracy
Product Details
| Storage: | 5000 | Measuring Area(mm): | 20°:10x10 60°:9x15 85°:5x36 |
|---|---|---|---|
| Screen: | Capacitive Touch Screen | Division Value: | 0.1GU |
| Tolerance: | ±1.2, ±1.2% | Language: | Chinese, English |
| Highlight |
Silk gloss meter,tri gloss meter,Ergonomic Sheen Gloss Meter |
||
Product Description
ISO 2813 Standard Three-angle gloss meter 2000GU Glossmeter NHG268 Intelligent Gloss Meter with large touchscreen
Brief Introduction
NHG268 three angles smart glossmeter, whose complete proprietary intellectual property rights are fully owned by Silk, was researched and developped complying with the international standard ISO2813 and China national standard GB/T9754, also the standard ASTM D 523 and ASTM D 2457.
Now NHG268 has been widely used by our customers all over the world in many industries, like painting, lacquer, ink, coating, leather, paper, printing, plastics, electronics, furnitures, wood, decorating, ceramics, tiles, metals, hardware, marble, electroplating, package, food, cosmetics, pharmacy, cloth, garment, textiles, traffic signage, etc.
Features
1. Three-angle gloss meter, measuring angle 20 ° / 60 ° / 85 °
2. 3.5 "TFT touch screen, 5,000 memory positions comes with PC software raportage
3. 20 ° 0-2000GU; 60 ° 0-1000GU; 85 ° 0-160GU
4. Highly accurate ± ± 0.1GU 0.2GU, ± 0.2% GU
5. ergonomic design
Technical Specification
| Parameters | Tri-angle Gloss Meter NHG268 |
| Measuring Angle | 20° & 60° & 85° |
| Measuring Area | 20°: 10x10mm 60°: 9x15mm 85°: 5x36mm |
| Measuring Range | 20°:0~2000GU 60°:0~1000GU 85°:0~160GU |
| Division Value | 0.1GU |
| Measurement Range Repeatability Reproducibility | 0-10GU 10-100GU 100-2000GU ± 0.1GU ± 0.2GU ± 0.2%GU ± 0.2GU ± 0.5GU ± 0.5%GU |
| Measurement Standard | Conform to the Working Requirements for JJG696 First Class Glossmeter |
| Chromaticity Response | Corresponding with CIE 1931(2°) under CIE C Light Source |
| Tolerance | ±1.2, ±1.2% |
| Measuring Time | 0.1s |
| Display Size | TFT 3.5" |
| Screen-touch | Yes, Capacitive Touch Screen |
| Data Port | USB |
| Language | Chinese, English |
| Battery | 3200mAh Li-ion Battery , more than 10000 times (within 8 hours) |
| Dimension | 160*75*90mm |
| Weight | 350g |
| Measuring Mode&Storage | Basic Mode: 1000 |
| PC Software | GQC6 Quality Control Software with QC Report Printing Functions and More Extended Functions |
| Operation Temperature | 0~40℃ (32~104℉) |
| Storage Temperature | -20~50℃ (-4~122℉) |
| Humidity | <85% Relative Humidity, No Condensation |
Standard Accessories
| Standard Accessories | |
| 1 | Power Adapter |
| 2 | USB Cable |
| 3 | User Manual |
| 4 | CD (Including QC Software) |
| 5 | Calibration Plate |
Frequently Asked Questions
1. Which models are the equivalent models to NHG268 Gloss Meter?
Answer: BYK4446 is the equivalent model to Silk NHG268.
2. Are you a trader or a manufacturer?
Answer: We Silk is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments and gloss meters. Our company and factory are located in Beijing which is famous for manufacturing. Welcome to visit us!
3. What's your main market.
Answer: We sell to the global market.
4. How long is your delivery time?
Answer: Generally it is 1-3 working days after the payment confirmed.
5. What is your payment terms?
Answer: The payment term is 100% T/T in advance.
6. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.
