Handheld UV Light Source UV Grating TS7700 3nh Spectrophotometer

Place of Origin Shenzhen China
Brand Name 3nh
Certification CE, TUV, FCC, RoHS, ISO9001
Model Number TS7700
Minimum Order Quantity 1Unit
Price Please send inquiry
Packaging Details 46*25*38cm, 4.5KG, Alluminum Box
Delivery Time 2-5 Days
Payment Terms T/T
Supply Ability 500 Units per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Optical Geometry D/8° SCE/SCI SCE & SCI
UV Light Source Yes Repeatibility ΔE*≤0.02
Inter-instrument Agreement ΔE*≤0.15 Measuring Aperture 8mm & 4mm
High Light

UV Grating 3nh Spectrophotometer

,

TS7700 3nh Spectrophotometer

,

1.5s Hunter Lab Spectrophotometer

Leave a Message
Product Description

Handheld Color Spectrophotometer 3NH TS7700 UV Grating Meter can Replace Minolta CM-2600D Spectrophotometer

1. Product Profile



TS7700 handheld spectrophotometer is a high-end precise color measurement instrument for surface color measurement and management, which can be widely applied in all kinds of industries, such as plastics and metals, paint and coating, furniture and wood, ink, printing and packaging, pharmaceuticals, cosmetics, fabrics, textiles and garments, electronics, tiles and decoration industry.



Built for performance and reliability, the Spectrophotometer TS7700 is a top-of-the-line measurement instrument designed to precisely evaluate the color and appearance of opaque and fluorescent samples. This high precision, versatile spectrophotometer is used to evaluate, reproduce, and help control the color and appearance of samples in a more effective, streamlined process. Its advanced capabilities and unwavering performance enable users to formulate and match color quality standards more efficiently, maintain consistency in each batch of material, and help communicate color seamlessly internally and throughout the supply chain. This makes the TS7700 ideal for color analysis, formulation, and quality control inspections within laboratory and manufacturing environments.



In one word, TS7700 color measurement spectrophotometer can be perfectly applied in any place that requires color control or color management.



2. Detailed Technical Parameter / Specification Form



Technical Parameter Items TS7700 Handheld Color Measuring Spectrophotometer
Product Category Optical Electronic Digital Color Testing Equipment
Product Name Handheld Color Measurement Spectrophotometer
Optical Geometry d/8°
Measuring Apertures ∅10mm/∅8mm + ∅5mm/∅4mm
Color Spaces CIE LAB, XYZ, Yxy, LCh, CIE LUV, s-RGB, HunterLab, βxy, DIN Lab99, Muncell(C/2)
Color Difference Formulas ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00, DIN ΔE99, ΔE(Hunter)
Repeatability Error ΔE*ab≤0.03
Inter-instrument Error ΔE*ab≤0.15
Other Colorimetric Index

WI (ASTM E313, CIE/ISO, AATCC, Hunter),

YI (ASTM D1925, ASTM 313),

MI (Metamerism Index),

Staining Fastness, Color Fastness, Color Strength,

Opacity, 555 Index, 8-degree Glossiness

Information Displayed Spectrogram/Data, Chromaticity Diagram/Values, Color Difference Values/Graph, Pass/Fail Result, Color Simulation, Color Offset/Deviation Direction
SCI/SCE SCI+SCE (SPIN+SPEX)
Viewing Angle 2° & 10°
Illuminating Lamps Combined Full Spectrum LED Lamps, UV Lamps
Lamps Life-span 5 Years, more than 3 Million times of measurements.
Integrating Sphere Size ∅40mm
Wavelength Range 400nm - 700nm
Wavelength Pitch 10nm
Semiband Width 10nm
Reflectance Range 0∼200%
Illuminants D65, A, C, D50, D55, D75, F1, F2(CWF), F3, F4, F5, F6, F7(DLF), F8, F9, F10(TPL5), F11(TL84), F12(TL83/U30), UV
Sensor Silicon Photodiode Array (Dual Row 40 Groups )
Spectroscope Flat Grating
Measurement Time 1.5s (About 5s for both SCI and SCE)
Data Storage Capacity 1000 pcs of Standards, 30000 pcs of Samples. (Once piece of data includes both SCI and SCE)
Data Transmission Port USB & Bluetooth
PC Terminal Software SQCX (for free)
Display Screen 3.5 inches TFT Capacitance Screen-touch Display
Language Built-in English, Chinese. (If need German, French, Spanish, Italian or Russia, please specify)
Built-in Battery 6000 times measurements in 8 hours.
Working Environment Temperature: 0∼40℃; Humidity: 0∼85% (No Condensation)
Storage Environment Temperature: -20℃∼50℃; Humidity: 0∼85% (No Condensation)
Standard Accessories White and Black Calibration Cavity, Φ4mm Flat+Tip, Φ8mm Flat+Tip Aperture, Power Adapter, USB Cable, PC Software SQCX, User Guide, Protective Cover, Wrist Strap.
Optional Accessories Mini Thermal Printer, Powder Test Box
Weight 600g
Dimension 129*76*217mm



3. Detailed Introduction to Instruments



3.1. High configuration of hardware: 3.5 inches colorful capacitance screen-touch display, showing more comprehensive colorimetric indexes in one screen, making your operation more convenient and freer, checking color spectrum reflectance rate data and graph very soon.



3.2. Dual row 40 groups Silicon Photodiode Array detector, making it more sensitive to colors.



3.3. Long life-span stable LED & UV LED lamps which can generate different kinds of light sources and color temperatures more accurately. LED lamps are famous for their durability which makes the instrument more stable.



3.4. UV light source, can measure fluorescent colors more accurately.






3.5. Pass/Fail test result indication, help you to decide if the color of the sample meets the requirement very promptly.



3.6. Color Offset/Deviation Direction indication between the standards and the samples which is definitely helpful for you to figure out the wanted color formulation.



3.7. SCI+SCE (SPIN+SPEX), can be measured simultaneously by pressing the button one time.






3.8. Reflection D/8 Geometry, the optical geometry which are most widely adopted in color measuring instruments.



3.9. Two measuring apertures: 4mm and 8mm, can measure the color of different kinds of targets from small ones to big ones.



3.10. All kinds of Color Spaces, Color Difference Formulas and Colorimetric Indexes, meet all the requirements for color measurement and color analysis.



3.11. Include all kinds of light source types.












3.12. Configured with a PC terminal software SQCX, more extended powerful functions for color data management can definitely facilitate your color management work.



3.13. USB and Bluetooth4.0, implement data transmission more convenient and quicker.



3.14. Built-in camera for aiming at the target to be measured precisely.






4. Company Profile



TS7700 Color Testing Spectrophotometer was developed and manufactured independently by Shenzhen 3nh/ThreeNH Technology Co., LTD. which is a state high-tech company who has been specializing in researching and developing, manufacturing and marketing surface color measuring instruments and equipment, gloss measurement meters and also color matching light cabinets for over 23 years, since founded in 1998.



We warmly welcome customers, partners and friends to visit our company and factory in Shenzhen, China.






GW6A9235 1231.jpg





5. Frequently Asked Questions



1. Can TS7700 spectrophotometer be equivalent to any models of world famous brand?

Answer: Yes, our TS7700 is equivalent to CM-700d of KONICA MINOLTA and Ci64 of X-rite.



2. Are you a trader or a manufacturer?
Answer: We 3nh is a manufacturer. We research and develop, design and produce, market and sell color measuring instruments and gloss meters.
Our company office, together with our factory are located in Shenzhen which is famous for manufacturing. Welcome to visit us!



3. What's your main market?
Answer: We sell to the global market.



4. How long is your delivery time?
Answer: Generally, it is 1-3 working days after the payment confirmed.



5. What is your payment terms?
Answer: The payment term is 100% T/T in advance. The first suggested payment method is via Alibaba platform here.



6. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.





Contact Information:



Contact Person: Clara Liu;

Email: L001@3nh.com;

Wechat & Whatsapp ID: +8613510310267;

Skype: clara.3nh



Related Knowledge about Spectrophotometer:



Color Space

CIE LAB
- L(Lightness)-0 is black,100 is white
- a(Red-Green)-positive values are red; negative values are green and 0 is neutral
- b(Blue-Yellow)-positive values are yellow;negative values are blue abd 0 is neutral

CIE LCH
L: Lightness,value is the same in each scale C:Chroma H:Hue Angle

dE Total Color difference
Delta-E is a measurement used to indicate how much a color deviates from an accepted standards.The higher the dE, the more inaccurate the color.
