| Measuring Angle: | 20° & 60° & 85° | Measuring Area(mm): | 20°:10x10 60°:9x15 85°:5x36 |
|---|---|---|---|
| Measuring Range(GU): | 1000gu | Standard: | GB/T9754, ASTM D 523,ASTM D 2457 |
| Software: | GQC6 | Data Port: | USB |
| Power: | Rechargeable Built-in Li-ion Battery | ||
| Highlight |
TFT Display Triangle gloss meter,1000GU Triangle gloss meter,3.5" TFT gloss meter |
||
Technical Specification
| Parameters | Tri-angle Gloss Meter HG268 |
| Measuring Angle |
20° & 60° & 85° Comply with Standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457 |
| Measuring Area | 20°: 10x10mm 60°: 9x15mm 85°: 5x36mm |
| Measuring Range | 20°:0~1000GU 60°:0~1000GU 85°:0~160GU |
| Division Value | 0.1GU |
| Measurement Range Repeatability Reproducibility |
0-10GU 10-100GU 100-2000GU ± 0.1GU ± 0.2GU ± 0.2%GU ± 0.2GU ± 0.5GU ± 0.5%GU |
| Measurement Standard | Conform to the Working Requirements for JJG696 First Class Glossmeter |
| Chromaticity Response | Corresponding with CIE 1931(2°) under CIE C Light Source |
| Tolerance | ±1.5, ±1.5% |
| Measuring Time | 0.1s |
| Display Size | TFT 3.5" |
| Screen-touch | Non |
| Data Port | USB |
| Language | Chinese, English |
| Battery | 3200m Ah Li-ion Battery , more than 10000 times (within 8 hours) |
| Dimension | 160*75*90mm |
| Weight | 350g |
| Measuring Mode&Storage |
Basic Mode: 1000pcs |
| PC Software | GQC6 Quality Control Software with QC Report Printing Functions and More Extended Functions |
| Operation Temperature | 0~40℃ (32~104℉) |
| Storage Temperature | -20~50℃ (-4~122℉) |
| Humidity | <85% Relative Humidity, No Condensation |
| Standard Accessories | Power Adapter, USB Cable, User Manual, CD (Including QC Software), Calibration Plate |
| Optional Accessories | Mini Printer |
Triangle gloss meter factory hg268 gloss meter 1000GU 0.1GU HG268 triangle glossmeter with 1000 gu PC software HG268 triangle glossmeter, whose complete proprietary intellectual property rights are fully owned by Silk, was researched and developped complying with the international standard ISO2813 ...
