Place of Origin	Shenzhen, China
Brand Name	3nh
Certification	CE,RoHs,ISO,etc
Model Number	CR1
Minimum Order Quantity	1pc
Price	300 USD
Packaging Details	Standard Export Package
Delivery Time	2 works days
Payment Terms	T/T,Paypal
Supply Ability	1000pcs/month

Model	SCI	Light Source	D65
Measuring Aperture	8mm	Color Space	CIELab
Delta E	<0.05	Observer Angle	10°
Measuring Time	1.0s	Color Spaces	CIE LAB, LCh
High Light	D/8 8mm Aperture 3nh Colorimeter , CR1 Manual Calibration 3nh Colorimeter , Illumination Locating Color Test Meter

Product Name & Model	CR1(Basic Edition)
Geometry	D/8(Diffuse illuminance, 8°reception, SCI), Conforms to standards CIE No.15,GB/T 3978.
Features	Used for color difference quality control in plastic electronics, paint and coating, textile and garment printing and dyeing, ceramics and other industries; Small size, easy to carry, search for the color cards through smartphone APP
Integrating sphere size	Φ20mm
Illuminant	Full spectrum LED light source
Spectro device	Filter spectro
Sensor	CMOS Dual light path sensor
Wavelength Range	400~700nm
Measuring Aperture	Φ8mm
SCI/SCE	SCI
Color Spaces	CIE LAB, LCh
Color Difference Formula	ΔE*ab
Other Color Index	/
Display Accuracy	0.1
Observer Angle	10°
Light source	D65
Display	Sample chromaticity value, color difference value, pass/fail result, color simulation, color deviation, reflectance (partly through mobile APP)
Measuring Time	1.0s
Repeatability	Color:ΔE*ab within 0.1(After warm-up calibration, the average value of measuring the whiteboard 30 times at an interval of 5s)
Metrology requirements	Non
Measurement Mode	Single measurement,Average measurement(2~99times)(Implemented through smartphone App)
Dimension	Ø30X100mm
Weight	88g
Battery	Lithium battery, can do tests continuously for 12000 times in a single full charge
Light source lifespan	5years more than 3 million times measurements
Display screen	IPS full color screen, 1.14 inch
Interface	Type C USB(just for recharge); blue-tooth 5.0
Data storage	Mass storage can be expanded through mobile APP
Data review	The instrument has no measurement data review function
White calibration	Non-contact automatic calibration
Settings	Instrument can set parameters
Language	Chinese,English
Working Temperature range	0~40℃,0~85%RH(No condensation),Altitude:lower than 2000m
Storage Temperature Range	-20~50℃,0~85%RH(No condensation)
Standard Accessories	Data cable, manual, calibration box, SQCX PC Color quality management software, MOBCCS APP (download from official website)
Optional Accessories	USB mini printer, powder test box
Note:	Technical parameters are for reference only, subject to actual instruments.
